BMW S 1000XR User Manual

Confirm selection.
Confirm settings.
Advance a menu step.
Scroll to the right in lists.
In the My Vehicle menu: ad-
vance one menu screen.
MENU rocker button
functions
NOTICE
Instructions given by the navig-
ation system are displayed in a
dialogue box if the Navigation
menu has not been called up.
Operation of the MENU rocker
button is temporarily restricted.
Short press the top section
of the MENU button:
In the Menu view, change up a
level.
In the Pure Ride view: change
the display for driver info status
line.
Long-press the top section
of the MENU button:
In the Menu view: call up
Pure Ride view.
In the Pure Ride view: change
operating focus to the Navig-
ator.
Short-press the bottom
section of the MENU button:
Change down a level.
No function if the lowest
hierarchical level has been
reached.
Long-press the bottom
section of the MENU button:
Change back to the last menu
after a previous menu change
effected by long-pressing the
top section of the MENU but-
ton.
Operating instructions in
the main menu
Operating instructions show
whether interactions are possible,
and which ones.
5
100
z TFT display

BMW S 1000XR Specifications

General

Displacement	999 cc
Max Power	165 hp (121 kW) at 11, 000 rpm
Max Torque	114 Nm (84 lb-ft) at 9, 250 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Aluminum composite bridge frame, partially self-supporting engine
Traction Control	Dynamic Traction Control (DTC)
Wheelbase	1, 548 mm (60.9 in)
Seat Height	840 mm (33.1 in)
Dry Weight	226 kg (498 lbs)
Fuel Capacity	20 l (5.3 gal)
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Twin disc, 320 mm, 4-piston radial calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
ABS	BMW Motorrad ABS Pro
