BMW S 1000XR User Manual

Press down firmly on the filler
cap of the fuel tank.
The fuel filler cap engages with
an audible click.
The fuel filler cap locks auto-
matically when the waiting time
expires.
The engaged fuel filler cap
locks immediately when you
secure the steering lock or
switch on the ignition.
Securing motorcycle
for transportation
Make sure that all components
that might come into contact
with straps used to secure the
motorcycle are adequately pro-
tected against scratching. Use
adhesive tape or soft cloths, for
example, for this purpose.
ATTENTION
Vehicle topples to side when
being lifted on to stand
Risk of damage to parts if vehicle
topples
Secure the vehicle to prevent it
toppling, preferably with the as-
sistance of a second person.
Push the motorcycle onto the
transportation flat and hold it in
position: do not place it on the
side stand.
ATTENTION
Trapping of components
Component damage
Do not trap components such
as brake lines or cable legs.
At the front, loop a strap over
the bottom fork bridge on each
side.
Pull the straps down and tight.
7
140
z Riding

BMW S 1000XR Specifications

General

Displacement	999 cc
Max Power	165 hp (121 kW) at 11, 000 rpm
Max Torque	114 Nm (84 lb-ft) at 9, 250 rpm
Transmission	6-speed
Final Drive	Chain
Frame	Aluminum composite bridge frame, partially self-supporting engine
Traction Control	Dynamic Traction Control (DTC)
Wheelbase	1, 548 mm (60.9 in)
Seat Height	840 mm (33.1 in)
Dry Weight	226 kg (498 lbs)
Fuel Capacity	20 l (5.3 gal)
Rear Suspension	Aluminum swing arm, central spring strut
Front Brakes	Twin disc, 320 mm, 4-piston radial calipers
Rear Brakes	Single 265 mm disc, single-piston caliper
ABS	BMW Motorrad ABS Pro
