Thread neck straps 2 using
a suitable tool on both sides
through the cheek / neck
pads 1. Ensure that the neck
straps are not twisted.
Thread chinstrap 1 on both
sides through the neck
straps 2 and cheek/neck
pads 3 into the inside of the
helmet.
Close the snap fasteners 1 on
both sides.
Insert pin of welt 1 into the
dedicated opening between
outer and inner helmet shell.
Insert welt 1 all around into the
helmet edge.
Insert the pin arrow of welt 1,
which has no contact yet, into
the designated opening on the
other side of the helmet.
Removing head pad
Loosen locking tab 1 and snap
fastener 2.
Loosen Velcro elements from
the centre bar and remove
head pad 3.
4
11
z
Maintenance
