Air conditioner
1 Airflow directed toward the wind-
shield and side windows
2 Airflow for the upper body
The side rotary dials allow you to
open and close the air supply
through an infinitely-variable range,
while the levers change the airflow
direction. The center rotary dial
controls the temperature of the air
as it flows out. Refer to page 103
3 Front footwell ventilation
4 Rear footwell ventilation
5 Air flow for the upper body in the
rear seat 103
6 Temperature 102
7 Air distribution toward
> the windows
> the upper body
> the footwell
An infinitely-variable range of
intermediate settings is also
available. Refer to page 102
8 Air supply 102
The climate control is active when
the blower is switched on.
9 Rear window defroster 73, 102
10 Cooling 102
11 Recirculated air mode 103
