152n
Under the cargo area floor in a pocket.
530us106
Front
1. Move the wiper to a fold-out position
(refer to page 69)
2. Lift the wiper arm and press the
securing spring (arrow)
3. Pull the wiper blade off toward the
wiper arm
4. Insert the new blade and snap it into
place.
Fold the wipers back down onto
the windshield before you turn the
ignition key to position 1 or 2 again. If
you do not, they could be damaged.<
530de300
Rear
1. Hold the wiper blade on the window
and remove/unclip the wiper arm at
the articulated joint (arrow)
2. Insert a new wiper blade and press it
on/clip it into the wiper arm.
Use only wiper blades approved
by BMW.<
