102n
1 Airflow directed toward the wind-
shield and side windows
2 Airflow for the upper body 104
3 Front footwell ventilation
4 Rear footwell ventilation
5 Airflow for the upper body in the rear
seat 104
6 Temperature 103
7 Air distribution 103
8 Air supply 103
9 Rear window defroster 103
10 Air conditioning 103
11 Recirculated-air mode 103
Air conditioner
530us222
