Model 670C Berkeley Nucleonics Corp. 24 of 96
The Marker Out BNC connector is located on the rear panel in the Model 670C-4C models. See
“Auxiliary Channels” section form more information.
The Trigger In BNC connector is located on the rear panel in the Model 670C-4C models. See “Auxiliary
Channels” section form more information.
The Model 670C Series instrument can use an external clock source to generate the sampling clock
frequency. The connector type is a SMA. See “Auxiliary Channels” section form more information.
This connector outputs the internal 10MHz reference clock used to synthesize the DAC sampling clock.
The connector type is a SMA. See “Auxiliary Channels” section form more information.
See “Auxiliary Channels” section form more information.
