Voltage High[V]
It defines the maximum level of the waveform expressed in Volts
Voltage Low[V]
It defines the minimum level of the waveform expressed in Volts
IMPORTANT NOTES
• The maximum value of repetitions is infinite: Repetitions[N]=Infinite. To set the repetitions to
infinite open the On-Screen Keyboard and press the “INF” button.
• Length[N] is the length of the selected sequencer entry
• The minimum entry length is 8 samples. The entry length granularity is:
o 1 if the entry length is > 384
o 8 if entry length is ≥ 8 and ≤ 384 samples
• You can insert the length of an entry in samples or time: press the Length[N] label to switch
from samples to time representation expressed by a Duration [s].
• The Waveform length is the original length of the waveform in term of number of samples
• The entry length can be different from the waveform length because the entry length is the
same for all the instrument channels while the waveform length can be different. In case the
entry length and the waveform length are different the original waveform will be manipulated
(resampled/cut/extended) to match the entry length.
