Model 670C Berkeley Nucleonics Corp. 73 of 96
As shown in the table detailing the different waveform types you can choose (see Parametric Waveform
Types paragraph), some of these (i.e., Pulse, Square, Sine) have Auto Calc.
What Auto Calc does is simple, it lifts you from the bothersome and sometime time-consuming task of
finding a setup which correctly synthesize the desired frequency. There are four different strategies, with
varying degree of freedom detailed in the following table.
Each
0
in the table means that you are able to freely change that parameter within reasonable boundaries
such as those specified by Shannon’s theorem; whilst the lock means that a parameter or pair of thereofs
are being automatically determined and aren’t directly customizable.
To change the employed strategy, tap the Auto Calc Options drop down button and then select the
strategy that best suits your needs from the submenu.
