Front Wheel
a. Loosely t the nuts and washers to the front
wheel axle. There is a ‘tab’ on the washer. This
must point inwards towards the wheel.
b. The tyres have a “tread”. It’s best to have this
facing forwards.
c. Lower the fork onto the wheel.
d. The “tab” on the washer ts into the little hole
in the fork. Fasten the domed nuts with the
15mm spanner.
e. If you can’t t the tyre through the gap
between the brake pads, you will need to
loosen the brakes rst to t the wheel. See
page 16. Alternatively you can simply squeeze
the deated tyre with your ngers, so that is
ts through the gap. You can inate the tyre
later.
Spin the wheel to check it is straight.
a. b.
c. d.
