NEUTRAL
REVERSE
1
FORWARD
A
P–16622
6808261
STOP
RUN
C
P–19199
START
18 Operation & Maintenance Manual
331/331E/334 Excavator
STARTING THE ENGINE
Key Switch (Base Controller)
Perform the PRE–STARTING PROCEDURE Page 16.
Put control levers (Item 1) [A] in the neutral position.
Move the engine speed control to low idle [B].
Turn the key to START [C]. If preheating is required, the
glow plugs will automatically cycle and the remaining
preheat time (in seconds) will show in the LCD. (Preheat
Icon will be ON [B].
Release the key when the engine starts. It will return to the
RUN position.
Stop the engine if the warning lights and alarm do not go
OFF. Check for the cause before starting the engine again.
Turn the key switch OFF to stop the engine.
Do not engage the starter for longer than 15
seconds at a time. Longer use can damage the
starter by overheating. Allow starter to cool for
one minute before using starter again.
I–2034–0700
Base Controller Shown
B
P–21183
To Next Page
