ALTERNATOR (Cont'd)
Alternator Belt Adjustment (743)
Open the rear door.
Remove the belt shield bolts.
Remove the belt shield from the engine
[A].
Loosen the adjustment bolt (Item 1) [B).
Move the alternator to set the belt tension at 5/16" (8 mm)
deflection with 15
Ibs. (7 kg) pressure [B].
Tighten the adjustment bolt.
Install the belt shield.
