S250 Bobcat Loader
PM-8 Operation & Maintenance Manual
OPERATOR CAB (CONT’D)
Raising The Operator Cab (Cont’d)
Figure PM-5
Remove the nuts and plates [Figure PM-5] (both sides)
at the front corners of the cab.
Figure PM-6
Lift on the grab handles and bottom of the operator cab
[Figure PM-6] slowly until the cab is all the way up and
the latching mechanism engages.
Advanced Control System (ACS)
WARNING
Never modify operator cab by welding, grinding,
drilling holes or adding attachments unless
instructed to do so by Bobcat. Changes to the cab
can cause loss of operator protection from rollover
and falling objects, and result in injury or death.
W-2069-1299
P-31289
P-31288
P-31267
