65 S450 Operation & Maintenance Manual
ENGINE SPEED CONTROL
Operation
Figure 37
The engine speed control (Item 1) [Figure 37] is located
alongside the door frame below the right panel.
Move the lever up to increase engine speed. Move down
to decrease engine speed.
Figure 38
SJC equipped machines have a foot operated engine
speed control pedal (Item 1) [Figure 38] in addition to the
engine speed control lever. The pedal is located on the
right side floor above the footrest.
LIFT ARM BYPASS CONTROL
Description
Figure 39
The lift arm bypass control (Item 1) [Figure 39], located
to the right of the operator’s seat, is used to lower the lift
arms if the lift arms cannot be lowered during normal
operations.
Operation
Perform the procedure below to operate the lift arm
bypass control:
1. Sit in the operator's seat.
2. Fasten the seat belt and lower the seat bar.
3. Turn the knob (Item 1) [Figure 39] 90° clockwise.
4. Pull up and hold the knob until the lift arms lower.
To Next Page
