119 S650 Operation & Maintenance Manual
OPERATING PROCEDURE (CONT’D)
Leveling The Ground Using Float (SJC - ‘ISO’
Pattern)
Figure 167
Press and hold the float button (Item 1) [Figure 167]
while the joystick is in neutral. While lowering the lift arms
(Item 2) [Figure 167], release the float button.
Tilt the bucket forward (Item 3) [Figure 167] to change
the position of the cutting edge of the bucket.
With the bucket tilted farther forward, there is more force
on the cutting edge and more loose material can be
moved.
Drive backward to level loose material.
To disengage, press the float button again or raise the lift
arms (Item 4) [Figure 167].
IMPORTANT
Never drive forward when the hydraulic control for lift
arms is in float position.
I-2005-1285
NA1688A
2
1
3
4
P-24820
P-24802
