121 S650 Operation & Maintenance Manual
TOWING THE LOADER
Procedure
Because of the design of the loader, there is not a
recommended towing procedure.
• The loader can be lifted onto a transport vehicle.
• The loader can be skidded a short distance to move
for service (EXAMPLE: Move onto a transport
vehicle.) without damage to the hydrostatic system.
(The tyres will not turn.) There might be slight wear to
the tyres when the loader is skidded.
The towing chain (or cable) must be rated at 1.5 times the
weight of the loader. (See Performance on Page 202.)
LIFTING THE LOADER
Single-Point Lift
WARNING
AVOID INJURY OR DEATH
• Before lifting, check fasteners on single point lift
and operator cab.
• Assemble front cab fasteners as shown in this
manual.
• Never allow riders in the cab or bystanders within
5 m (15 ft) while lifting the machine.
W-2007-0910
The loader can be lifted with the Single-Point Lift which is
available as a kit from your Bobcat loader dealer.
The Single-Point Lift, supplied by Bobcat, is designed to
lift and support the Bobcat loader without affecting roll
over and falling object protection features of the operator
cab.
Figure 171
Attach lift to lift eye [Figure 171].
NOTE: Be sure the lifting equipment is of adequate
size and capacity for the weight of the loader.
(See Performance on Page 202.)
NA1789
