ELECTRICAL SYSTEM (CONT’D)
Fuse And Relay Location / Identification (Cont’d)
Figure 235
The location and amperage ratings are shown in the table below and on the decal [Figure 235]. Relays are identified by
the letter “R” in the AMP column.
REF
ICON
DESCRIPTION AMP REF
ICON
DESCRIPTION AMP REF
ICON
DESCRIPTION AMP
1 Alternator 15
11 Glow Plugs R 21 Bobcat Controller 25
2 Heater / HVAC 25
12 Fuel Shutoff R 22 ACS Controller 25
3 Front Lights 20
13 Cab Switched
Power
5 23 Attachments 25
4 Rear Lights 15
14 Bucket Position 15 24 Not Used - -
5 Starter R
15 Wiper / Washer 25 25 Auxiliary
Controller
25
6 Front Lights R
16 Switched Power &
Back-up Alarm
(Standard/ACS)
25 26 Drive Controller &
Back-up Alarm
(SJC)
25
7 Heater / HVAC R
17 Switched Power 25 27 Accessories &
Front Horn
25
8 Rear Lights R
18 Switched Power 25 28 Power Port 15
9 Switched Power R
19 Traction 30
10 Traction R 20 Fuel Shutoff 30
6
7
19
18
5
17
11
13
15
8
10
20
12
14
16
9
1
2
3
4
21
22
23
24
25
26
27
28
NA3151
