206 S650 Operation & Maintenance Manual
(S650) LOADER SPECIFICATIONS (CONT’D)
Tyres
Fuel Consumption
Environmental
Temperature Range
Heavy Duty (Standard) 12.00 - 16.5, 12 Ply Rating
Heavy Duty Offset (Option) 12.00 - 16.5, 12 Ply Rating
Heavy Duty Poly Fill (Option) 12.00 - 16.5, 12 Ply Rating
Severe Duty (Option) 12.00 - 16.5, 12 Ply Rating
Severe Duty Poly Fill (Option) 12.00 - 16.5, 12 Ply Rating
Solidflex (Option) 33 x 6 x 11
Super Float Offset (Option) 33 x 15.50 - 16.5, 12 Ply Rating
Recommended Pressure Inflate tyres to MAXIMUM pressure shown on the side wall of the tyre. DO NOT
mix brands of tyres used on the same loader.
Engine Load Full - 100% High - 70% Medium - 50% Low - 30%
Fuel Consumption Rate Per Hour 17,0 L
(4.5 U.S. gal)
13,2 L
(3.5 U.S. gal)
11,4 L
(3.0 U.S. gal)
9,5 L
(2.5 U.S. gal)
NOTE: The engine fuel consumption chart is to be used as a guideline only. The actual results may vary.
Noise / Vibration Levels Uncertainties (If Applicable)
Noise level LpA (EU Directive 2000/14/EC) 101 dB(A) - - -
Operator position noise level (ISO 6396) 82,3 dB(A) +2,5 / -0 dB(A)
Whole body vibration (ISO 2631-1) (limit 0,5 m/s2)
0,76 m/s
2
0,38 m/s
2
Hand-arm vibration (ISO 5349-1) (limit 2,5 m/s2)
1,54 m/s
2
- - -
Operation and storage -26 - +43°C (-15 - +110°F)
