41 S650 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION
Overview
Figure 6
The left panel [Figure 6] is described in more detail.
(See Left Panel on Page 42.)
Figure 7
The right panel [Figure 7] is described in more detail.
(See Right Panel (Standard Key Panel) on Page 46.),
(See Right Panel (Keyless Start Panel) on Page 47.) or
(See Right Panel (Deluxe Instrumentation Panel) on
Page 48.)
Figure 8
The left and right switch panels [Figure 8] are described
in more detail. (See Left Switch Panel on Page 50.) and
(See Right Switch Panel on Page 50.)
Figure 9
The left and right side lower panels [Figure 9] are
described in more detail. (See Left Side Lower Panel on
Page 51.) and (See Right Side Lower Panel on Page 51.)
P-90668A
P-90212J
Standard Key
P-85285 P-90819H
Keyless Start Deluxe Instrumentation
P100045A
P-85304B
P-85282
P-85267D
