42 S650 Operation & Maintenance Manual
INSTRUMENT PANEL IDENTIFICATION (CONT’D)
Left Panel
Figure 10
The left instrument panel [Figure 10] is the same for
Standard Key Panel, Keyless Start Panel and Deluxe
Instrumentation Panel equipped machines.
The table on the facing page shows the DESCRIPTION
and FUNCTION / OPERATION for each of the
components of the left panel.
