58 S650 Operation & Maintenance Manual
OPERATOR CAB
Description
The Bobcat loader has an operator cab (ROPS and
FOPS) as standard equipment to protect the operator
from rollover and falling objects. The seat belt must be
worn for rollover protection.
WARNING
Never modify operator cab by welding, grinding,
drilling holes or adding attachments unless
instructed to do so by Bobcat Company. Changes to
the cab can cause loss of operator protection from
rollover and falling objects, and result in injury or
death.
W-2069-0200
Cab Light
Figure 27
The Cab Light [Figure 27] is located above the
operator’s left shoulder.
Push this side of the switch (Item 1) to turn the light ON.
Place the switch in the middle position (Item 2) to turn the
light OFF. Push this side of the switch (Item 3)
[Figure 27] to turn the light ON and OFF with the door.
Door Operation
This machine may be equipped with a Front Door.
Figure 28
Push the knob (Item 1) and pull the handle to open the
front door. A lock is provided in the knob (Inset)
[Figure 28] to lock the front door when the loader is not
in use.
Figure 29
Pull the front door closed using the handle (Item 2)
[Figure 29].
Pull the lever (Item 1) toward you to unlatch the front
door. Push on the handle (Item 2) [Figure 29] to open
the front door.
P-85586
1
2
3
P-90351A
1
P-90684E
1
2
