95 S650 Operation & Maintenance Manual
STARTING THE ENGINE (CONT’D)
Keyless Start Panel (Cont’d)
NOTE: Make sure both hand controls (ACS / AHC) or
joysticks (SJC) are in the neutral position
before starting the engine. Do not move the
levers or joysticks from the neutral position
when turning the key switch to RUN or START
with the BICS™ activated.
WARNING
AVOID INJURY OR DEATH
• Fasten seat belt, start and operate only from the
operator’s seat.
• Never wear loose clothing when working near
machine.
W-2135-1108
Figure 117
(ACS) Select hand control or foot pedal operation (Item
1) [Figure 117] if equipped with ACS.
OR
(SJC) Select ‘ISO’ or ‘H’ Control Pattern (Item 2)
[Figure 117] if equipped with SJC.
Figure 118
Press the PRESS TO OPERATE LOADER button (Item
1) [Figure 118] to activate the BICS™ and to perform
hydraulic and loader functions.
(SJC) The current drive response setting will be
displayed briefly in the data display (Item 2) each time the
PRESS TO OPERATE LOADER button (Item 1)
[Figure 118] is pressed.
NOTE: (SJC) The light of the current switch position
(ISO or H) will flash, which will indicate
PRESS TO OPERATE LOADER is required.
The light will flash when the key switch is ON
and continue to flash until the PRESS TO
OPERATE LOADER button is pressed,
thereafter the light will become solid. If the
mode (ISO / H) is changed while driving, the
active mode light will remain solid and the
pending mode light will flash. When operation
of the machine is returned to neutral, the
active mode light will then turn off and the
pending mode light will continue to flash until
the PRESS TO OPERATE LOADER button is
pressed.
WARNING
AVOID INJURY OR DEATH
When an engine is running in an enclosed area, fresh
air must be added to avoid concentration of exhaust
fumes. If the engine is stationary, vent the exhaust
outside. Exhaust fumes contain odorless, invisible
gases which can kill without warning.
W-2050-0807
P-85307S
1
ACS
P-85307U
2
SJC
P-90726A
1
2
