96 S650 Operation & Maintenance Manual
STARTING THE ENGINE (CONT’D)
Deluxe Instrumentation Panel
WARNING
AVOID INJURY OR DEATH
• Engines can have hot parts and hot exhaust gas.
Keep flammable material away.
• Do not use machines in atmosphere containing
explosive gas.
W-2051-1086
Perform the PRE-STARTING PROCEDURE. (See PRE-
STARTING PROCEDURE on Page 88.)
Figure 119
Set the engine speed control to the idle position
[Figure 119].
NOTE: Loaders with a Deluxe Instrumentation Panel
have a permanent, randomly generated
Master Password set at the factory. Your
loader will also be assigned an Owner
Password. Your dealer will provide you with
this password. Change the owner password
to one that you will easily remember to
prevent unauthorised use of your loader. (See
Changing The Owner Password on Page 196.)
Keep your password in a safe place for future
needs.
NOTE: The Password Lockout feature can be used to
allow starting of the loader without a
password. (See Password Lockout Feature on
Page 197.)
Figure 120
Turn the key switch to RUN (Item 2) [Figure 120]. The
indicator lights on the left instrument panel will come ON
briefly and the Instrument Panel / monitoring system will
do a self test.
Use the numeric keypad (Item 1) [Figure 120] to enter
the password.
Figure 121
The machine will cycle the air intake heater automatically
based on temperature. The engine preheat icon (Item 1)
will be ON and the cycle time remaining (Item 2)
[Figure 121] will show in the data display.
When the engine preheat icon goes OFF, turn the key
switch to START (Item 3). Release the switch when the
engine starts and allow it to return to the RUN position
(Item 2) [Figure 120].
P-90525A
P-90212K
1
3
2
P-76461B
2
1
