03. ASSEMBLY INSTRUCTIONS
FITTING THE CARRIER ON THE BICYCLE
Take off all components from the bag (2 parts).
Cut the security device to remove the frame holder (E)
from the steel rod (A1). Then, pull the frame holder (E)
down to release it.
1 2
EN
E
E
Remove the 2 bolts (E4) and washers (E2) from the frame
holder (E). Use the Allen key (E1).
3
E4
E1
A1
E1
E
E3
