Fig.1 Fig.2
INSTALLATION FOR THE BODY AND THE CL EAN WATER TANK
Turn thelidof cleanwater tank counterclockwise as shown inFig.3, and then fill the clean
water tank withpurewater as shown inFig.4. Thewater level must not exceedthe
maximumwater level marked ontheclean water tank. Andthen turn thelidof cleanwater
tank clockwise as shown in Fig.5 to tightenit. After finish filling water, make thetank lid
downwards andtheninsert the cleanwater tank into thecorrespondi
ng positionof the
body as shown in Fig.6. Thereis a fastener insidethe body, andtheclean water tank is
installedwell in positionafter you hearing asoundof "click" (see Fig.7) .
Fig.3 Fig.4 Fig.5 Fig.6 Fig.7
INSTALLATION FOR THE BODY AND THE DIRTY WATER TANK
Insert thedirty water tank into thecorresponding positionof thebody as shown inFig.8.
Thereis a fastener at thedirty water tank, and thedirty water tank is installedwell in
positionafter you hearing asound of "cli
ck" (seeFig.9) .
Fig.8 Fig.9
INSTALLATION FOR THE ROLLER BRUSH
Insert the roller brush into thecorresponding position at thefloor brush as shown in Fig.10.
Thereis a fastener at thefloor brush, andtherolle
r brush is installedwell inpositionafter
you hearing asoundof "click" (seeFig.11) .
Fig.10 Fig.11
7 8
INSTALI ATION OF THE APPLIANCE INSTALLATION FOR THE ROLLER BRUSH
Counterclockwise
Clockwise
