Boca Micro - Default Chapter; Table of Contents

1
Table of Contents Page
FCC Notice & Warranty Information 2
1.0 Introduction 3
2.0 Unpacking the printer 3
3.0 Important Safety Information 4
4.0 Installation 5
5.0 Configuration 5
6.0 Standard Interface Pinouts 6
7.0 Thermal Paper – Theory & Specifications 7
8.0 Maintenance and Adjustments 8
8.1 Paper Guide and Print Head Assembly 8
8.1.1 Load Switch and Tear Opto 9
8.1.2 Thermal Print Head 11
8.1.3 Rubber Drive Roller 12
8.1.4 Ticket Width Adjustment 13
8.2 Logic Board 14
8.2.1 Logic Board (Removal) 14
8.2.2 Logic Board (Installation) 15
8.3 General Cleaning 15
9.0 Spare Parts List 15
10.0 Troubleshooting Guide 18
Appendix A 20
