PERFORMANCE SPEC I FI CA TIONS
AND ROUGHING-IN DI MEN SIONS
Leave ample room for servicing when the wa ter heater is in -
stalled – do not block ac cess to the burner, inspection door,
handholes or con trols. Leave room to pipe the unit and connect
the fuel and elec tric i ty.
CAUTION:
The rec om mend ed
water tem per a ture
setting for normal
res i den tial use is
120
O
F.
361E
72E
SIZES AND CAPACITIES
(shipping weights are complete assembly, including burners and controls)
MODEL
STORAGE
CAPACITY
BTUH
INPUT
FIRING
RATE
STANDARD
VOLTAGE
MOTOR
SHIPPING WEIGHT
STANDARD ASME
541E
* Nipple not furnished ** Under drain valve
on 72E only
HOT
OUTLET *
COLD
INLET
DRAIN
ALT INLET/
RETURN **
BURNER SPECIFICATIONS
MODEL/OEM # NOZZLE PRESSURE
72E CARLIN EZ-2HP/9833222J72E 1.25X70
O
B 150 PSI
WAYNE MSR/371-019B 1.50X80
O
B 100 PSI
RIELLO R35.5/C8512221 1.25X60
O
B 150 PSI
RIELLO 40F10/ 1.25X60
O
B 150 PSI
BECKETT AF / BK8-160 or BK8-180 1.50X80
O
B 100 PSI
361E CARLIN 201CRD/98285000B361E 2.50X70
O
B 150 PSI
WAYNE EH/371-026 3.00X80
O
A 100 PSI
541E CARLIN 201CRD/98285000B541E 4.00X70
O
B 130 PSI
WAYNE EH/371-028 4.50X80
O
B 100 PSI
72E 67 GAL. 199,000 1.50 GPH 120V 60HZ 1/7 HP 550 LBS. ––
361E 91 GAL. 415,000 3.00 GPH 120V 60HZ 1/4 HP 1105 LBS. 1125 LBS.
541E 83 GAL. 623,000 4.50 GPH 120V 60HZ 1/4 HP 1330 LBS. 1340 LBS.
MODEL A B C D E
72E
58
” 28” 20” 16” 8” 1
1
/
2
”* 1
1
/
2
” 3/4” 1
1
/
2
”
361E
67” 31
1
/
2
” 26” 23” 9” 2”* 1” 3/4” 2”
541E
66” 34” 30
1
/
2
” NA 10” 2”* 2”* 3/4” 2”
