BOCK FK40 - Removal of Roller Bearings

36
09665-07.2021-Gb
10 I Disassembly of the compressor
12
Removal of the roller bearings
Position in
parts list
Parts list position: 2150
Tools: Pulling apparatus
Working course
2150, 730
2150
312
- With the pulling apparatus pull out the roller bearing from the front bearing ange
If a pulling apparatus is not available, the front bearing ange may be heated for approx. 15 minutes in a pre-heated
(220°C) baking oven. Afterwards the roller bearing can be pressed out by hand.
- Press out the roller bearing from the compressor body
- Take out the tolerance ring, if there is any
INFO Use oil, if necessary!
CAUTION Risk of burns!
Parts are hot! Use protective gloves!
INFO Use oil, if necessary!
