52
09665-07.2021-Gb
11
Installation of the oil lter
Position in
parts list
Parts list position: 2130
Tools: Allen key 10 mm, spanner SW 19
Working course
490
500
510
- With the allen key, screw on the lter into the hole in the body and tighten it
- Install gasket
- Screw on the M22x1.5 mm plug and tighten it
12 I Assembly of compressor
100 Nm
INFO Observe the tightening torques!
