Body Solid G2B - Page 31

11
STEP
31
Selector Rod Top Bolt (98) must be threaded a
minumum of 1/2” into the Selector Rod (33), and
Jam Nut (102) tightened securely against spring
lock washer (101) to ensure proper connection.
Check the Jam Nut (102) once a week to make
sure it is tight.
WARNING
!
!
High
Pulley
Cable
Start here at
Double Pulley
Holder (CA) by
routing the
cable here.
Diagram 1
Cable Installation
Diagram 2
Pulley Installation
Diagram 1A
Cable Installation
