16
STEP
41
#1
#2
Apply weight stack numbers to the Weight
Stack Plates (87). Start at the Top Plate (29)
with the number 1, and the first plate
should be number 2. The following Weight
Stack Plates (87) should be numbered in
sequential order down through the stack.
NOTE 1
NOTE 2
This is the top view of the two Weight Stack Shrouds.
Note the shape of each shroud for proper placement.
3/4” flat side
2” flat side
To Next Page
