Adjustments
3. MULTI HIP (AD) ADJUSTMENT
A. Grasp the Multi Hip Arm (AD).
B. Pull the Pop Pin (111) in the Multi Hip Arm (AD) to release.
C. Adjust the Multi Hip Arm (AD) to the desired position.(depending on the exercise you are
performing).
D. Release the Pop Pin (111) and make sure it is fully engaged into the selector hole.
4. BACK PAD (BB) ADJUSTMENT
A. Grasp the Back Pad (BB).
B. Turn the T-Shaped Pop Pin (106) on the Back Pad Holder (S) counter clockwise to
unlock it, and then pull the T-Shaped Pop Pin (106) to release Back Pad Adjuster (T).
C. Adjust the Back Pad (BB) to the desired position.
D. Release the T-Shaped Pop Pin (106) and make sure it is fully
engaged into the selector
hole of the Back Pad Adjuster (T). Turn T-Shaped Pop Pin (106) clockwise to lock it in
place.
E. For certain exercises you may wish to change the angle of the Back Pad. Pull the
Pop Pin (90) on the Back Pad Adjuster (T), this will allow you to change to the
desired angle.
44
