45
28
Hardware
(To Scale)
Part# 22 M8x16 Hex Head Bolt (Full Thread) Qty. 4
Part# 23 M8x70 Hex Head Bolt (Partial Thread) Qty. 2
Part# 25 M8x75 Hex Head Bolt (Partial Thread) Qty. 2
Part# 20 M12x90 Hex Head Bolt (Partial Thread) Qty. 1
Part# 21 M12x100 Hex Head Bolt (Partial Thread) Qty. 4
