Body Solid GDR-60 - Step 1: Main Frame Assembly

8
S T E P
1
Be careful to assemble all components
in the sequence they are presented.
A. Insert two Foot Caps (3) into each Main Base Frame (A).
B. Insert End Cap (4) into each Main Base Frame (A).
C. Assemble lower Rack (B) to both Main Base Frame (A) using:
 Four1(M12x75atallenhead)
 TwoC(plate)
 Four2(M12nylonlocknut)
D. Assemble upper Rack (B) to both Main Base Frame (A) using:
 Four1(M12x75atallenhead)
 TwoC(plate)
 Four2(M12nylonlocknut)
E. Congratulations! The GDR-60 installation is complete.
