Body Solid GPR400 - STEP 1; Step 1 Assembly Instructions

8
STEP
1
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. DO NOT wrench tighten until instructed.
Some components may be pre-assembled. Nylon lock nuts will not fully screw onto
bolts, they must be wrench tightened to fully go on.
1A. AttachSteelPlates(F)tobothBaseFrames(A)using:
8 - (#1) M16x110mm Hex Head Bolt
16 - (#3) M16 Regular O.D. Washer
8 - (#5) M16 Nylon Lock Nut
NOTE #1:
Please refer to the drawing for the correct bolt hole locations.
1B. AttachUprights(B)toSteelPlates(F)using:
8 - (#1) M16x110mm Hex Head Bolt
16 - (#3) M16 Regular O.D. Washer
8 - (#5) M16 Nylon Lock Nut
NOTE #2:
It is recommedated to install the equipment with at least two persons.
