Bodyfriend PHANTOM - Installation Part 03: Side Panels; Side Panel Connection Procedure

10
BODYFRIEND Massage chair
aa
a b c
Installation Part 03
STEP 5. Connecting the Side Panel (Arm Unit)
01
Connect the air hose as depicted below.
02
Attach the side panel to
the main body in the direction
of the arrow indicated in the
󽗉gure below.
03
After the side panel is
attached, put the circular
cover back on and rotate
clockwise. Then, fasten
with a screw (a > b > c).
