BODYMAX B2 - Parts List

1L PEDAL JD-301（9/16"（,L 1
1R PEDAL JD-301（9/16"（,R 1
2 END CAP1 70*30*1.5 4
3 CARRIAGE BOLT GB/T 12-1988 M8*42 4
4 REAR STABILIZER WELDING 1
5 FLAT WASHER GB/T 95-2002 8 4
6 DOMED NUT "GB/T 802-1988 M8
(H=16mm)"
4
7 SPRING ADJUSTMENT KNOB φ57*62 (M16*1.5) 1
8 PLASTIC SLEEVE 50*25*1.5 2
9 LOCK NUT M33*1*4 2
10 VERTICAL SEAT POST WELDING 1
11 END CAP2 40*20*1.5 2
12 SEAT POST WELDING 1
13 SEAT PVC98-2 1
14 STOPPER φ32*37/(M8X25) 4
15 FRONT STABILIZER WELDING 1
16 MAIN FRAME WELDING 1
17 HANDLEBAR POST WELDING 1
18 HANDLE BAR WELDING 1
19 SPRING WASHER GB/T 859-1987 8 8
20 BOLT GB/T 70.2-2000 M8*16 8
21 HANDLEBAR COVER 115*89*75 (60g) 1
22 B0TTLE HOLDER 117*85*90 1
23 B0TTLE XS-003(1#) 500ML 1
24 END CAP 3 50*25*1.5 2
25 LOCKING KNOB PE+Q235/φ52*47 (M8x15) 1
26 FLAT WASHER 1 φ32*φ8.2*2 1
27 SENSOR SR-202 1
28 FIXING NUT 1 GB/T 6177.2-2000 M10*1.25 2
29 CRANK END CAP φ23*7.5 2
24
Indoor Cycle B2
8.2 Parts List
No. Name Specication Qty.
