8
STEP 3 ASSEMBLE HANDLEBAR AND STEM
1. Insert the Handlebar Stem (20) into the Front tube of the
Main Frame (1) . You will be able to adjust the height
of the Handlebar Stem and then using the pre-installed
Locking Lever (18). If you do not have room to turn the
handle on the locking lever . It can disengage from the
covered screw by simply pulling outward on the handle.
Then place the handle where needed to complete
tightening , release and it will be re-engage with the cover
screw. Remember to not make any adjustment past the
marked safety line.
2. Remove the pre-installed Sliders Safety Screw (14) on the
front of the Handlebar Stem (20) . Then slide Handlebar
(11) into the Handlebar Stem. Re-insert the Sliders Safety
Screw and tighten . This Sliders Safety Screw (14) keeps
the Handlebar from sliding all the way off.
2
0
