9
STEP 4 SADDLE AND SEAT POST ASSEMBLY
1. Insert the Seat Post (15) into the rear tube on the Main Frame
(1) . You will be able to adjust the height of the seat post and
then tighten using the pre-installed Locking Lever (18). If you
do not have room to turn the handle on the Locking Lever. It
can disengage from the covered screw by simply pulling
outward on the handle . Then place the handle where needed
to complete tightening, release, and it will re-engage with the
covered screw. Remember to not make any adjustments past
the marked safety lien.
2. Attach the Saddle (17) to the top Saddle Rod (76) and tighten by
nut (13) . Adjust the Saddle Slider's (16) to your desired position
and tighten by Locking Lever (18).
1
5
13
17
