BODYMAX CF485+ - Page 7

STEP 02
3
4
8
9
10
11
18
19
15
20
2
19
1. Attach Pulley (8) to Weight Base Tube (2) with Bolt M10*50 (15), two Washers 10 (19) and Lock Nut
M10 (20).
2. Attach Guide Rod (3) and Sliding Weight Post (4) to Weight Base Tube (2) with Sliding Sleeve (11) and
two Square Neck Bolts M10*70 (18).
3. Attach Olympic Spring Clip (10) and Weight Holder (9) to Sliding Weight Post (4).
