Part list:
Part No. Description Q’ty Part No. Description Q’ty
1 Main frame 1 53 Foam (HDR) D30*5T*530L 2
2 Front stabilizer 1 54 Foam (HDR) D23*5T*680L 2
3 Square neck bolt M8*1.25*93L 2 55 Mushroom cap D1 1/4”*45L 2
4 Adjustable foot cap 2 56 Spring D3*D19*67L 1
5L Left foot cap 1 57 Tension cable D1.5*640L 1
5R Right foot cap 1 58 Bolt M6*1.0*15L 16
6 Curved washer D22*D8.5*1.5T 14 59 Allen bolt M8*1.25*50L 1
7 Spring washer D15.4*D8.2*2T 10 60 Flat washer D21*D8.5*1.5T 2
8 Domed nut M8*1.25*15L 4 61 Crank axle 1
9 Allen bolt M8*1.25*20L 4 62 Round magnetic 1
10 Handlebar post 1 63 Screw ST3.5*1.27*15L 8
11 Supporting tube for pedal 2 64 Computer 1
12 Supporting tube for Movable
handlebar
2 65 Handle pulse 2
13 Bearing #99502ZZ 10 Handle pulse cable 2
14 Allen bolt M8*1.25*95L 2 66 Flat washer D25*D8.5*2T 4
15 Half ball cap 2 67 Front computer bracket 1
16 Fixing nut 1 68 Rear computer bracket 1
17 Allen bolt M8*1.25*100L 2 69 Front pedal axle 2
18 Nylon nut M8*1.25*8T 2 70 Fixed plate for idle wheel 1
19 Rear stabilizer 1 71 Flat washer D14*D6.5*0.8T 16
20 Square neck bolt M6*1*45L 4 72L Left fixed handlebar 1
21L Left pedal 1 72R Right fixed handlebar 1
21R Right pedal 1 73 Flat washer D14*D6.5*0.8T 4
22 Adjustable round wheel 2 74 Cover (Left) 2
23 Upper cover (Right) 2 75 Cover (Right) 2
24 Anti-loose nut M10*1.25*10T 2 76 Bearing #2203-2RS 2
25 Motor 1 77 Club knob 4
26 C-ring D22.5*D18.5*1.2T 2 78 Adaptor 1
27 Electric cable 1 79 Screw S-40 2
28 Sensor cable 1 80 Screw ST4*1.41*20L 2
29 Upper computer cable 1 81 Inner tube 1
30 Lower computer cable 1 82 Nylon nut M6*1*6T 1
31 Axle cover 2 83 Allen bolt M8*1.25*30L 1
32 Round cap 2 84 C-ring S-16 (1T) 3
33L Left crank 1 85 Bolt M6*65L 1
33R Right crank 1 86 Nut M6*1*6T 1
34 Screw ST4*1.41*20L 6 87 Nylon washer D6*D19*1.5T 1
35 Multi-groove belt 1 88 Fixed bracket for magnetic 1
36L Left chain cover 1 89 Nut M8*1.25*6T 2
36R Right chain cover 1 90 Screw M5*0.8*10L 2
37 Fly wheel 1 91 Screw ST4*1.41*15L 10
38 Upper cover (Right) 2 92 Buffer 4
39 Side cover 2 93 Flat washer D24*D16*1.5T 1
40 Bolt M8*1.25*20 4 94 Plastic cover 1
41 Screw ST4.2*20L 6 95 Flat washer D50*D10*3T 1
42 Round chain cover 2 96 Flat washer D239D17*1.2T 4
43 Bearing #6004ZZ 2 97 Front foot cover(outer) 2
44 Bolt M8*52L 1 98 Front foot cover(inner) 2
45 Nylon nut M8*1.25*8T 3 99 Inner tube 2
46 Plastic flat washer
D50*D10*1.0T
1 100 Knob 2
47 Waved washer D21*D16.2*0.3T 2 101 Fixing ring 2
48 Flat washer D13*D6.5*1.0T 1 102 Chest belt 1
49 Handlebar post cover 1 103 Bolt M5*0.8*15L 2
50 Flat washer D28*D8.5*3T 1 104 Bottle hold 1
51 Spring D1.0*55L 1 105 Bottle 1
52L Left movable handlebar 1
52R Right movable handlebar 1
