Boeing 747 - Page 36

3
3
1
2
4 4
4
1
2
3
UP
FWD
A
A
NOTES: _____
A-A
AREAS WHERE CRACKS HAVE OCCURRED
INBOARD AND OUTBOARD INSERTS (NOT SHOWN) ARE REMOVED FOR THE INSPECTION
GUIDE
TRANSDUCER
TRANSDUCER
UPPER LINK
SIDE BRACE
DIAGONAL BRACE
FAIRING
ENGINE NACELLE & STRUT
FUSE PIN INSPECTION SURFACES
INSPECTION AREA
2130634 S0000459159_V1
Inspection Area on Strut
Figure 1
747
NONDESTRUCTIVE TEST MANUAL
PART 4 54-30-06
Page 6
Nov 15/2015D6-7170
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ALL
