CALIBRATION SCREEN DISPLAY FOR A BONDED AREA
OF FULL SCREEN WIDTH
10 AND 20 PERCENT
SIGNAL BETWEEN
PART OF THE TTU
PUT THE
HIGHEST
SCREEN HEIGHT
80 PERCENT OF FULL
SET THE SIGNAL TO
SET THE GATE
THRESHOLD AT
20
PERCENT OF
FULL SCREEN HEIGHT
2134432 S0000460243_V1
Calibration Screen Display Examples
Figure 3 (Sheet 1 of 2)
747
NONDESTRUCTIVE TEST MANUAL
PART 4 57-50-01
Page 7
Nov 15/2015D6-7170
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ALL; 747 AIRPLANES WITH COMPOSITE KRUEGER
FLAPS
