CALIBRATION SCREEN DISPLAY FOR A FOAM TAPE OR A DISBOND AREA
SIGNAL
TRANSMITTED
LOSS OF
2134433 S0000460244_V1
Calibration Screen Display Examples
Figure 3 (Sheet 2 of 2)
747
NONDESTRUCTIVE TEST MANUAL
PART 4 57-50-01
Page 8
Nov 15/2015D6-7170
