Bofa V600 - V600 System Specifications; Unit Performance and Dimensions; Filter Types, Efficiency, and Carbon

System Specifications
Unit: V600
Capacity: 350 m³/hr (206cfm)
Weight: 35Kg (77lbs)
Motor: Centrifugal Fan
Output: 1.1Kw
Electrical supply: 115-230V
Hertz: 50/60Hz
Full Load Current: 12.5 A
Noise Level: Below 54dB (A)
(at typical operating speed)
Size:
Metric
(mm)
Imperial
(inches)
Height 590 23.1
Depth
458
18
Width 396 15.6
Filters:
Filter Type Surface
area
Efficiency
Pre Filter (F8) 4.2m
2
95% @ 0.9 microns
HEPA Filter
(Combined
filter)
2.1 m
2
99.997% @ 0.3µ
Filter Type Carbon
Type
Amount
Carbon filter
(combined
filter)
Activated
Carbon
8.5kgs
Environmental operating range:
Temperature: +5
o
C to + 40
o
C
Humidity: Max 80% RH up to 31
o
C
Max 50% RH at 40
o
C
01
