Tab.: 17.2
Pos.
Description
Item No.
NKBD-
6
NKBD-
12
NKBD-
18
NKBD-
24
NKBD-
30
NKBD-
36
NKBD-
42
10
Fluid tank NKBD-6
1960
-
-
-
-
-
-
10
Fluid tank NKBD-12
-
1961
-
-
-
-
-
10
Fluid tank NKBD-18
-
-
1962
-
-
-
-
10
Fluid tank NKBD-24
-
-
-
1963
-
-
-
10
Fluid tank NKBD-30
-
-
-
-
1964
-
-
10
Fluid tank NKBD-36
-
-
-
-
-
1965
-
10
Fluid tank NKBD-42
-
-
-
-
-
-
1966
11
Spacer disk transducer-ABS
1889
1889
1889
1889
1889
1889
1889
12
Transducer TU-42-X
9024
9024
9024
9024
9024
9024
9024
13
Spring disk DIN-137-A2-B3.5
1837
1837
1837
1837
1837
1837
1837
14
Hexagon nut DIN-934-A2-M3
1599
1599
1599
1599
1599
1599
1599
15
Insulating bush IB 6
1184
1184
1184
1184
1184
1184
1184
16
Oscillator board 4/3 SMD
9004
9004
9004
9004
9004
9004
9004
17
Float switch, level
1509
1509
1509
1509
1509
1509
1509
18
Float switch, dry
1875
1875
1875
1875
1875
1875
1875
19
Screw-in socket 3/8" Ø15 mm, BSP parallel thread
2631
2631
2631
2631
2631
2631
2631
20
Sieve water filter, stainless steel, Ø 18mm
1864
1864
1864
1864
1864
1864
1864
21
O-ring 21x2,5mm - NBR70
1893
1893
1893
1893
1893
1893
1893
22
Multihousing overflow
1876
1876
1876
1876
1876
1876
1876
23
Multihousing supply/discharge
1912
1912
1912
1912
1912
1912
1912
24
Disk DIN-7349-A2-3,2
1913
1913
1913
1913
1913
1913
1913
25
Spring ring DIN-127-A2-B3
1914
1914
1914
1914
1914
1914
1914
26
Seal ring G½"x1,5 hard PVC
1833
1833
1833
1833
1833
1833
1833
27
Straight screw-in connection D/d=15/12,5 mm, G½''
1845
1845
1845
1845
1845
1845
1845
28
Basin cover NKBD-6
1953
-
-
-
-
-
-
28
Basin cover NKBD-12
-
1954
-
-
-
-
-
28
Basin cover NKBD-18
-
-
1955
-
-
-
-
28
Basin cover NKBD-24
-
-
-
1956
-
-
-
28
Basin cover NKBD-30
-
-
-
-
1957
-
-
28
Basin cover NKBD-36
-
-
-
-
-
1958
-
28
Basin cover NKBD-42
-
-
-
-
-
-
1959
29
Closing sheet 06x
1724
-
-
-
-
-
-
29
Closing sheet 12x
-
1725
-
-
-
-
-
29
Closing sheet 18x
-
-
1726
-
-
-
-
29
Closing sheet 24x
-
-
-
1733
-
-
-
29
Closing sheet 30x
-
-
-
-
1734
-
-
29
Closing sheet 36x
-
-
-
-
-
1735
-
29
Closing sheet 42x
-
-
-
-
-
-
1736
30
Disk DIN-125-A2-4,3
1532
1532
1532
1532
1532
1532
1532
31
Lensehead screw DIN-7985-A2-M4x8
1618
1618
1618
1618
1618
1618
1618
