3. Scope of delivery
Duct Humidifier NKBD
Fig.: NKBD-24
Installation and operating instructions
Stop cock Ø 10 mm
4. Optional accessories
Item no.
Type
Description
Illustration
0001196
Tube, PA
D/d=10/8 mm,
blue
Tube water supply D = 10 mm (blue)
0001847
Tube, PE
D/d=14/11 mm,
nature
Tube water drainage D = 14 mm (nature)
2000105
Mounting brackets
For easy installation of NKBD on a
mounting frame in the air duct, made of
V2A-stainless steel, incl. adjustable foot.
Needs: 2 pcs for NKBD-6 to NKBD-24
3 pcs for NKBD-30 to NKBD-42
200140..
Vertical frame
To build a mounting frame in the air duct,
made of V2A-stainless steel,
height adjustable from 500-700 mm or
700-1200 mm or 1200-2000 mm
PU = 1 set (2 pcs)
