Tab.: 17.3
Control housing centre section NKBD
Lensehead screw DIN-7985-A2-M2x10
Spring ring DIN-127-A2-B2
Hexagon nut DIN-934-A2-M2
Lead-through terminal L, N
Distance bolt Ms M3x12 outside/ M3 inside
Snap-In distance bolt M3x12
Control board Hyg UB/P-D, RB/P-D, NKBD
Suppressor diode, 1.5KE, 82CA,
Lensehead screw DIN-7985-A2-M4x8
Spring ring DIN-127-A2-B4
Hexagon nut DIN-934-A2-M4
Control housing cover NKBD
Control housing bottom NKBD
Seal ring G½"x1,5 hard PVC
Elbow screw-in connection rotatable G½“
Solenoid supply valve 1/8" (SP)
Seal for solenoid valve supply (SP)
Device plug for solenoid supply valve (SP)
Seal ring G1/8"x1,5 hard PVC
Rubber seal 25x25x1 with Ø8
Reducing nipple G1/8"-G½"
Sieve water filter, stainless steel, Ø 18mm
Elbow screw-in connection rotatable G½“
Elbow screw-in connection rotatable G1/8“
Solenoid drain valve 2x3/8" (SP)
Seal for solenoid valve discharge (SP)
Device plug for solenoid discharge valve (SP)
Adapter overflow/discharge
Straight screw-in connection D/d=15/12,5 mm, G½''
Tube PVC fabric D/d =15/12.5 mm, blue
Locking nut DIN-985-A2-M3
Lensehead screw DIN-7985-A2-M3x16
Hexagon nut DIN-934-A2-M3
