Product description 2.1 Technical data – compressor
Page 14 BOGE Operating instructions for C 16 N...C 30 N, C 16 F N...C 30 F N series screw compressors
Technical data C 16 N...C 30 N, part 2
Type
C 16 N C 20 N C 25 N C 30 N
Oil filling quantity
Total oil filling quantity [gallon]
2.6 2.6 2.6 2.6
Oil topping up quantity
between min. + max. [gallon]
0.3 0.3 0.3 0.3
Intake air temperature
– min. [°F]
+ 41 + 41 + 41 + 41
– max. [°F]
+ 113 + 113 + 113 + 113
Air cooling
Cooling air requirement
– free-standing installation [cfm]
2179 2886 3534 4123
– with supply and exhaust air duct [cfm]
1001 1473 1826 2032
– free fan pressing [psig]
0.0087 0.0087 0.0087 0.0087
Water cooling
Cooling air requirement
– free-standing installation [cfm]
1178 1178 1178 1178
– with supply and exhaust [cfm]
589 589 589 589
Required cooling water quantity
– delta t = 15 K [cfm]
0.35 0.48 0.59 0.71
– delta t = 30 K [cfm]
0.18 0.24 0.3 0.35
Max. cooling water quantity [cfm]
0.74 0.74 0.74 0.74
Cooling water inlet temperature
– min. [°F]
+ 41 + 41 + 41 + 41
– max. [°F]
+ 86 + 86 + 86 + 86
Cooling water outlet temperature
– max. [°F]
+ 113 + 113 + 113 + 113
Cooling water pressure
– min. [psig]
29 29 29 29
– max. [psig]
145 145 145 145
Operating pressure values
1)
1)
Compressors for other operating pressures p
min
= p
max
– 15 psig.
(factory settings)
– p
max
= 100 psig: switch-off pressure p
max
[psig]
100 100 100 100
switch-on pressure p
min
[psig]
85 85 85 85
– p
max
= 115 psig: switch-off pressure p
max
[psig]
115 115 115 115
switch-on pressure p
min
[psig]
100 100 100 100
– p
max
= 150 psig: switch-off pressure p
max
[psig]
150 150 150 150
switch-on pressure p
min
[psig]
135 135 135 135
– p
max
= 190 psig: switch-off pressure p
max
[psig]
190 190 190 190
switch-on pressure p
max
[psig]
175 175 175 175
Safety valve
Activation pressure at:
– p
max
= 100 psig [psig]
160 160 160 160
– p
max
= 115 psig [psig]
160 160 160 160
– p
max
= 150 psig [psig]
160 160 160 160
– p
max
= 190 psig [psig]
203 203 203 203
