Product description
BOGE Operating instructions for S 40-2...S 341 / SF 40-2...SF 220 series screw compressors
Technical data for S 101 to S 341, part 2
Technical data2.1
Type S 101 S 125 S 150 S 151 S 180 S 220 S 271 S 341
Oil filling quantity
Oil receiver volume [gallon] 29 29 29 46 46 46 61 61
Total oil filling quantity [gallon] 16 16 16 24 24 24 34 34
Oil topping up quantity
between min. + max. [gallon] 2.4 2.4 2.4 4.0 4.0 4 4.8 4.8
Intake air temperature
– min. [°F] + 41 + 41 + 41 + 41 + 41 + 41 + 41 + 41
– max. [°F] + 113 + 113 + 113 + 113 + 113 + 113 + 113 + 113
Cooling air requirement
– free-standing installation [cfm] 11800 18900 18900 18900 28700 28700 32960 38846
– with supply and exhaust [cfm] 5900 9400 9400 9400 14350 14350 16480 19423
– (air duct)
– free ventilator pressure [inch/H
2
O] 0.24 0.24 0.24 0.24 0.24 0.24 0.24 0.24
Cooling air requirement
– free-standing installation [cfm] 2000 2000 2000 2000 5880 5880 5880 5880
– with supply and exhaust [cfm] 1000 1000 1000 1000 2940 2940 2940 2940
Required cooling water quantity
– delta t = 15 K [cfm] 2.41 2.881 3.528 7.997 4.23 5.127 6.409 7.997
– delta t = 30 K [cfm] 1.20 1.440 1.764 3.998 2.11 2.564 3.205 3.998
Max. cooling water quantity [cfm] 5.30 5.3 5.3 8.0 7.1 7.1 8.0 8.0
Cooling water inlet temperature
– min. [°F] + 41 + 41 + 41 + 41 + 41 + 41 + 41 + 41
– max. [°F] + 86 + 86 + 86 + 86 + 86 + 86 + 86 + 86
Cooling water outlet temperature
– max. [°F] + 113 + 113 + 113 + 113 + 113 + 113 + 113 + 113
Cooling water pressure
– min. [psig] 30 30 30 30 30 30 30 30
– max. [psig] 146 146 146 146 146 146 146 146
Operating pressure switch
1
)
(factory settings)
– p
max
= 100 psig: Switch-off press. p
max
[psig] 100 100 100 100 100 100 100 100
87
Switch-on press. p
min
[psig]87878787878787
– p
max
= 115 psig: Switch-off press. p
max
[psig] 115 115 115 115 115 115 115 115
Switch-on press. p
min
[psig] 100 100 100 100 100 100 100 100
– p
max
= 125 psig: Switch-off press. p
max
[psig] 125 125 125 125 125 125 125 125
Switch-on press. p
min
[psig] 110 110 110 110 110 110 110 110
– p
max
= 150 psig: Switch-off press. p
max
[psig] 150 150 150 150 150 150 – 150
Switch-on press. p
min
[psig] 130 130 130 130 130 130 – 130
– p
max
= 190 psig: Switch-off press. p
max
[psig] 190 190 190 190 190 190 – 190
Switch-on press. p
min
[psig] 174 174 174 174 174 174 – 174
Safety valve
Activation pressure at:
– p
max
= 100 psig [psig] 160 160 160 160 160 160 160 160
– p
max
= 115 psig [psig] 160 160 160 160 160 160 160 160
– p
max
= 150 psig [psig] 160 160 160 160 160 160 160 160
– p
max
= 190 psig [psig] 203 203 203 203 203 203 203 203
Air cooling
1
) Compressors for other operating pressures P
min
= P
max
minus (–) 14.5 psig.
Water cooling
